Leica RTC360 3D レーザースキャナー
高速かつ機動性に優れた高精度の3Dリアリティキャプチャ・ソリューション
Leica RTC360 3Dリアリティキャプチャソリューションは、周囲の状況を3次元データ化し、高速で使いやすく高精度のポータブル・ハードウェアおよびソフトウェアを提供し、現場およびオフィスの業務の効率性と生産性を改善します。RTC360 3Dレーザースキャナーは、現場の詳細なデータをキャプチャして精確で信頼性の高い3次元モデルを生成し、専門家が複雑なプロジェクトの管理を行えるようするソリューションです。
- RTC360は持ち運びがしやすく、限りなく自動化され、直観的な操作で使用できる、高い生産性を念頭に置いて設計された製品です。また、高機能な3次元レーザースキャナーのRTC360に加えて、リアルタイムで自動的にスキャンデータの合成処理を行う携帯端末用アプリのLeica Cyclone FIELD 360、オフィス用ソフトウェアの Leica Cyclone REGISTER 360を効果的に組み合わせることで、3次元モデルデータを業務プロセスにシームレスに統合できます。
- 高解像なHDR画像を含むスキャンデータを、2分未満でキャプチャできます。
- 自動的にスキャンステーションの移動位置を記録し、予め器械点のレジストレーションを行うことで、現場での手動操作の必要性を排除します。
- より良い計画の反映、現場の実情共有、およびチーム全体と現状を認識合わせをするために、キャプチャしたデータに情報タグを付与して、リアリティデータを拡張することができます。
- キャプチャしたデータを Cyclone FIELD 360 から Leica TruView Cloud に直接パブリッシュして、インポートと合成をする前にプロジェクト情報をすばやく共有できます。
Fast
The Leica RTC360 laser scanner makes 3D reality capture faster than ever before. With a measuring rate of up to 2 million points per second and advanced HDR imaging system, the creation of coloured 3D point clouds can be completed in under two minutes. Plus, automated targetless field registration (based on VIS technology) and the seamless, automated transfer of data from site to office reduce time spent in the field and further maximise productivity.
Agile
Small and lightweight, the Leica RTC360 scanner’s portable design and collapsible tripod mean it’s compact enough to fit into most backpacks, ready to be taken anywhere. Once on-site, easy-to-use, one-button operation makes for fast, hassle-free scanning.
Precise
Low noise data allows for better images, resulting in crisp, high-quality scans that are rich in detail and ready for use in a range of applications. Combined with Cyclone FIELD 360 software for automated registration in the field, the Leica RTC360 scanner offers outstanding precision that can be checked on-site.
Registraton in the field
As part of the RTC360 solution, the Cyclone FIELD 360 app links the 3D data acquisition in the field with the laser scanner and data registration in the office with Cyclone REGISTER 360 PLUS. On-site the user can automatically capture, register and examine scan and image data. The user interface combines easy handling of complex calculations with a graphical user guidance that offers a remarkable user experience, also for novice users.
